Rohde & Schwarz MXO 4 Oscilloscope Review
Автор: shabaz
Загружено: 2023-04-20
Просмотров: 3769
Описание:
This 30-minute video reviews the features and functions of the R&S MXO 4 Oscilloscope. It covers the following topics:
00:00 - Start
01:10 - Who is the MXO 4 for?
02:59 - Instrument, Probes and User Interface
05:45 - Current, Power, Noise: Ferrites and Inductors
07:22 - Current, Power, Noise: FPGA Power Measurement
09:23 - Spectral Analysis: PSU Noise Spectrum
11:00 - Spectral Analysis: RF Modulation
12:37 - Spectral Analysis: Conducted and Radiated EMC
17:23 - Waveform Generation: Frequency Response Analysis
19:47 - Waveform Generation: RF Mixer Testing
21:22 - Waveform Generation: LoRa Transmission
22:42 - Memory, Logic, Protocols: SPI Flash File System
25:11 - Memory, Logic, Protocols: RS-485 DMX Troubleshooting
26:43 - Summary: What's Good and What's Bad? What's Missing?
For an unboxing video, see • R&S MXO 4 Series: What's in the Box?
For the full written review, see https://community.element14.com/produ...
