Cootie is a micro plane using a Rogallo wing (kite).
It uses only 2 channels to fly: throttle (up and down) and rudder to turn. Total weight is 16g including battery.
Hardware description:
F929/939 main board = RX flysky, 2 servos, 1 esc, 1 optional servo
Motor: coreless diameter 7mm, length 20mm, shaft 1mm
Propeller: DD2510 or DD3020 cut to fit
120mAh lipo for 15 minutes of fly time
Depron 3mm for the body
1mm carbon rod for the wing
1.5mm carbon rod for the mast
3D printed parts for the Rogallo structure
Construction files, tips and more photos are available here: http://cncpartage.fr/object.php?id=202
