DORRIES CTE 400 V 8 / 8.000 CNC vertical borer - Karussel drehmaschine vertical turning lathe 1 - 2

Описание: Dörries CNC Vert. boring mill
single column with displaceable table


Make : Dörries - Germany
Typ : CTE 400 / V 8
Age : 1983
Serial.No : 50816

Chuck Ø : 4.000
Max. turning Ø : 8.000
Max. turning height table-tool : 3.000
Max. height table -- crossrail : 3.300

Stroke vertical tool holder : 1.761
Stroke horizontal tool holder : 2.480

Dimensions tool holder : 50 x 50
Table load : 80.000
Feeds mm/min : 1 -- 1.000
Rapid feed mm/min : 1 -- 6.000
Feed crossrail mm/min : 350

Dimensions :
Height : 8.400
Width : 8.000
Length : 8.700
Weight : 110.000 Kg





Please Note: The above information has been obtained to the best of our ability and belief from, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details





MACH4METAL
metalworking machinery














Torq on chuck : 100.000 Nm
Cutting power support: 75.000 Nm
Speeds vario in 3 steps
from 1 up to 63 /min.


Min. distance table side head : 2.100
Side head stroke Vertical : 2.000
Side head stroke Horizontal : 1.000

CNC controlled FANUC A2
Side support / side head
Ballcrews + Slide roller guideways
Displaceable table electric
Circular interpolation
