Hooking Treadmill Motor Blue Wires: SCR, MC60 and MC-2100 Treadmill Motor Controller Power Supply

Описание: Blue wires, Some videos say "You don't need them, don"t use them" but THIS IS A BAD IDEA. Hooking them up is simple and adds a safety feature. This video goes over the basic hookup of blue wires to several different power supplies.
