16'' Swing 40'' Centers Tos SN40 ENGINE LATHE
Автор: MachineryValues Inc
Загружено: 2018-01-03
Просмотров: 10891
Описание:
16"/23-1/2" X 40" TOS ENGINE GAP BED LATHE
MODEL: SN 40 C, S/N: 08 40 1096 0001, NEW: 1996
SPECIFICATIONS:
SWING OVER WAYS......................... 16"
SWING IN GAP............................ 23-1/2"
SWING OVER CARRIAGE..................... 9"
CENTER DISTANCE......................... 40"
SPINDLE BORE............................ 2"
SPINDLE SPEEDS (24)..................... 22.4 - 2000 RPM
THREADING INCH.......................... 1 - 80 TPI
METRIC........................ .5 - 40 MM
TAILSTOCK TAPER......................... #5MT
TAILSTOCK QUILL TRAVEL.................. 7"
DIMENSIONS.............................. 4' X 8' X 5'H
WEIGHT.................................. 3,500 LBS
EQUIPPED WITH:
10" 3-JAW CHUCK
14" 4-JAW CHUCK
STEADY REST
FOLLOW REST
QUICK CHANGE TOOL POST
LONGITUDINAL & CROSS FEEDS
RAPID TRAVERSE
MICROMETER CARRIAGE STOP
COOLANT SYSTEM
- 7-1/2 HORSE POWER MAIN MOTOR
