2020 INFINITI Q50 - Heater and Air Conditioner

Описание: "This video is copyrighted material of Nissan North America, Inc. and should not be copied, edited, or reproduced without the permission of Nissan.

This is the control panel for the heater and air conditioner system.

Press the CLIMATE button on the control panel to show the climate control options on the lower screen.

Press THIS button and the system will automatically regulate and maintain fan speed, air flow, and temperature.

If FAN SPEED, AIR FLOW MODE, or DEFROST settings are manually adjusted, the system will switch from AUTO mode to your control.

Use THESE buttons to manually set the desired temperature for each side of the vehicle.

To switch back to driver control, touch the DUAL key to the OFF position.

Press THIS button to select from the available air flow modes. THIS icon indicates air will flow from the defroster outlets and foot outlets. THE arrows indicate whether the center and side vents, or the foot outlets are active.

Press THIS button to recirculate air inside your vehicle. This increases A/C efficiency and helps to block outside odors.

Press again to draw in fresh outside air, improving your vehicle's defogging performance.

If so equipped, touch THIS air recirculation key to set the air intake to automatic.

Press the CLIMATE button and then touch THIS key to manually turn the air conditioner ON.

In hot or humid conditions, a visible mist may be seen coming from the vents. This does not indicate a malfunction.

To defrost or defog front and side windows, press THIS button.

The indicator light on the A/C key may also illuminate because the A/C compressor is activated to help dry the air and improve window clearing performance. The air can still be fully warmed with the A/C activated.

For windshield deicing, set the temperature to maximum heat with the fan set to HIGH.

Press THIS button to defrost or defog the rear window and the outside mirrors. If not turned OFF manually, this function will automatically deactivate in a period of time.

There is a temperature sensor on top of the dashboard that regulates the automatic heater and air conditioner settings. Please keep this area clear of papers and other materials.

To turn the system OFF, push the ON/OFF button.

You can return to automatic control of the heater and air conditioner system at any time by pressing THIS button.

Please see your Owner’s Manual for important safety information, system limitations, and additional operating and feature information."
