FOSTEX F120A FT90H
Автор: seas- lyd
Загружено: 2014-02-19
Просмотров: 98387
Описание:
2way speaker using Fostex F120A 5" full range driver and Fostex FT90H horn super tweeter with Alnico magnet both. These vintage drivers are designed over 20~30 years ago but F120A is still available. Modern FEM computer aided design speaker unit like Seas and Scanspeaks sounds smooth, clear, perfect low distortion, in comparison, vintage high efficient unit with Alnico magnet sounds straight, vivid and high contrast.
Direct heated triode single ended DIY amplifier using EH-2A3 (non NFB) is well matched.
Driver: Fostex F120A, FT90H with Acoustic lens
Cabinet: SAKAE KB10 (Rubber wood)
Low-pass filter 6dB/oct (Fostex air-core coil)
High-pass filter 12dB/oct (Solen air-core coil, Benic film capacitor)
Cross-Over: 12 kHz
System
TEAC-VRDS25
DIY 2A3 SE-non NFB
2A3: Electro-Harmonix Gold
6SL7 (SRPP Drive): Hytron
5U4 (Rectifier): Raytheon
