JPBX 325 & 336 Caltrain Trains Meet | *Hinged Gates* W Meadow Dr. Railroad Crossing Palo Alto CA

Описание: Nov 4, 2025 11:18am
Caltrain commuter rail trains meet here at the West Meadow Drive railroad crossing on the JPBX Caltrain Peninsula Sub in Palo Alto, California. This is one of several Caltrain crossings that have been converted to hinged gate crossings due to the new above OCS wiring for the EMU Stadler trainsets and additional reasons. This is the second crossing I've filmed with hinged gates.

Caltrain - Northbound
JPBX 325
JPBX 326
Stadler EMU KISS Trainsets

Caltrain - Southbound
JPBX 336
JPBX 335
Stadler EMU KISS Trainsets

Crossing Info
City: Palo Alto, California
Line/Crossing Owner: Caltrain (JPBX)
Line User(s): Caltrain, UP (2 Locals)
Bell Sequence: Ring till gates start rising

Right Pedestrian Gate
Gate Light: NEG Clear Gate LEDs "Alstom-Aurora Style"
Mechanism/Counterweight Arms: WCH
Base: WCH
Install: Caltrain early 2010s, Installed 2010

Right Shoulder Signal
Bell: WCH E-Bell - Type 3
Lights: 2 pairs of 12x24 inch GE Harmon Fading LEDs/WCH Lights (90s)
Junction Box: WRRS
Gate Lights: NEG Clear Gate LEDs "Alstom-Aurora Style" on hinged gate
Mechanism/Counterweight Arms: WCH
Base: WCH
Install: Caltrain 1990s

Left Pedestrian Signal
Bell: WCH E-Bell - Type 3
Lights: 3 pairs = Main - 2 pairs of 12x24 inch GE Harmon Fading LEDs/WCH Lights (90s), Side - 1 pair of 12x24 inch WCH 2nd Gen Miller Felpax LEDs/WCH Lights (00s)
Junction Boxes: WRRS & WCH
Gate Lights: RECO Gate LEDs
Mechanism/Counterweight Arms: WCH
Base: WCH
Install: Caltrain 1990s

Left Pedestrian Gate
Gate Light: NEG Clear Gate LEDs "Alstom-Aurora Style"
Mechanism/Counterweight Arms: WCH
Base: WCH
Install: Caltrain early 2010s, Installed 2010

Left Shoulder Signal - Safetran 80s Cantilever
Lights: 3 pairs of 12x24 inch GE Harmon Fading LEDs/Safetran Lights (Hawker Siddley Era)
Junction Boxes: Safetran
Gated Mast
Bell: WCH E-Bell - Type 2
Lights: 1 pair of 12x24 inch WCH 2nd Gen Miller Felpax LEDs/WCH Lights
Junction Box: WRRS
Gate Lights: 2 NEG Clear Gate LEDs "Alstom-Aurora Style" & 1 RECO Gate LED
Mechanism/Counterweight Arms: WCH with WRRS arms
Base: WCH
Install Of Whole Signal: Caltrain 1990s

Right Pedestrian Signal
Bell: WCH E-Bell - Type 3
Lights: 2 pairs of 12x24 inch GE Harmon Fading LEDs/WCH Lights (90s)
Junction Boxes: WRRS & WCH
Gate Lights: RECO Gate LEDs
Mechanism/Counterweight Arms: WCH
Base: WCH
Install: Caltrain 1990s

This crossing owned by Caltrain (JPBX) is an mixed signal build install crossing. The pedestrian signals and roadway signals are Caltrain JPBX 1990s signal installs with changes overtime to its bells, lights, some light heads gates, and gate lights and even some added lights. The pedestrian gates are Caltrain early 2010s signal installs.

Camera
Sony FX30 Cinema Line + Tamron 17mm - 300mm
