Irene House 9181 Power Recliner Assembly
Автор: Irene House
Загружено: 2021-11-22
Просмотров: 3525
Описание:
This video shows us how to install the chair. Please see the details of each step.
1. Here we have all the parts of the recliner we need.
2. The pillow, two arm rests, back, wings of the back, and the recliner base. Also, we have a power adapter and the power supply cord here.
3. The first step is to attach the arms. There are two locking clips. To put the arm on, you need to align the clips from the top, once they're aligned, push down.
4. And we do the same thing for this side.
5. Then we install the backrest.
6. Place the back in the seat of the chair, you’ll see the wires.
7. This one is for power supply, this is the remote control.
8. This one is for the power supply of lumbar support motor, which should be connected with this wire sticking out of the backrest.
9. You can see the red marks on both ends. Remember to clip in place.
10. Then, remove the package of the remote control. Cut the cable ties carefully, so we can hang the remote control on the side of the recliner.
11. Before assemble the back, you should notice there are also two locking clips. Align the clips on each side of the back. Slide the clips on and firmly push down. You'll hear a "click" when it's done.
12. Then it comes to the wings of the back.
13. Align the clips, push down.
14. Do the same thing for this side.
15. Put the pillow here.
16. Then we come to the power adapter. Connect this end to the motor and clip in place. And connect the two ends of the power adapter.
17. Plug it to an outlet.
18. Now we can activate the recliner.
19. This button is to control the footrest, this one is to control the backrest, and this one can control the lift.
#irenehouse9181
