Teardown of Anker Prime 200W 6 Ports GaN Charger

Описание: You can buy it on Amazon: https://amzn.to/3XZhmQF

If you wanna buy the tester of ChargerLAB POWER-Z, you can visit our Amazon store:
USA: https://amzn.to/4dHst6B
Germany: https://amzn.to/4dDuxN4

Introduction
---------------------------------------------------------------
ANKER has launched a 200W desktop charging station, which belongs to the Anker Prime series. It has four USB-C ports and two USB-A ports. The four USB-C ports all support 100W output power, the USB-A ports support 22.5W output power, and it supports intelligent output power distribution.
It supports an input voltage of 100~240V. It can charge laptops, tablets, phones, and headphones at the same time. Next, let's take it apart to see its internal components and structure.

Bill of materials (BOM)
------------------------------------------
Model: A2683
Bridge Rectifier: GK GBU1510
PFC Controller: SouthChip SC3202
PFC MOSFET: Innoscience INN700D140C
PFC Rectifier: JINGDAO MURL860F
AHB GaN IC: DONGKE DK3718AD
Optocoupler: Everlight EL1019
Synchronous Rectifier Controller: HYASiC HY923
Synchronous Rectifier: HRmicro HRG100N045G
Buck Protocol Chip: iSmartWare SW3561
VBUS MOSFET: HRmicro HRT30N08J
Synchronous Buck MOSFET: iSmartWare SWT40N45
MCU: Chipsea CS32L015K8V6

Chapter
----------------------------------
0:00 Intro
1:29 Test
3:27 Teardown
4:45 Analysis
10:09 Summary
