FPV FREESTYLE TRICKS GUIDE // ImpulseRC Alien 5" // Mode2 // FPV TUTORIAL

Описание: My actual Setup:
Frame: LMultirotors - LM2 V2 ► http://bit.ly/lm2v222
TBS Tango Radio ► http://bit.ly/tbstang
TBS Crossfire TX Module ► http://bit.ly/tbscrot
TBS Crossfire Micro Receiver V2 ► http://bit.ly/tbscror
TBS Unify HV 5G8 ► http://bit.ly/tbsunhv
TBS Triumph Antenna ► http://bit.ly/tbstriu
Hero 5 Session ► http://bit.ly/goprh5s
Goggles Fatshark Dominator V3 ► http://bit.ly/dominv3
Tattoo Lipo 1300 4s 45C
Motolab Tempest F4 ► http://bit.ly/mtltmp4
Aikon Sefm 30A Esc
EMAX RS2205S-2300 ► http://bit.ly/emax2205
HQProps 5x4x3
RTF Weight 565 grams

Video Setup:

Frame: ImpulseRC Alien 5”
FlightController: Motolab CycloneFC Betaflight 2.8.1
Esc: Aikon Sefm 30A Esc
Motors: Cobra 2204-2300 Motor
Propellers: HQProps 5x4x3
VideoTX: Fx799T vtx
Antennas: Aomway Antenna
HD Cam: Gopro Hero4 Session
Fpv Cam: HS1177 FPV Cam
Battery: Tattoo Lipo 1300 4s 45C
Radio: FrSky Taranis Radio
Reiceiver: FrSky X4R Reiceiver
Goggles: Fatshark Dominator V3 http://www.banggood.com/Fatshark-Domi...


Don’t forget to like, share e Subscribe!!
Thanks for watching!

#fpvfreestyle #fpv #dronefreestyle

Instagram: @lorisemmefpv

BetaFlight/MOTOLAB 2.8.1 Jun 8 2016 / 13:23:01 (c0b00fd)
dump master

mixer
mixer QUADX
mmix reset
smix reset


feature
feature -RX_PPM
feature -VBAT
feature -INFLIGHT_ACC_CAL
feature -RX_SERIAL
feature -MOTOR_STOP
feature -SERVO_TILT
feature -SOFTSERIAL
feature -GPS
feature -FAILSAFE
feature -SONAR
feature -TELEMETRY
feature -CURRENT_METER
feature -3D
feature -RX_PARALLEL_PWM
feature -RX_MSP
feature -RSSI_ADC
feature -LED_STRIP
feature -DISPLAY
feature -ONESHOT125
feature -BLACKBOX
feature -CHANNEL_FORWARDING
feature -TRANSPONDER
feature -AIRMODE
feature -SUPEREXPO_RATES
feature VBAT
feature RX_SERIAL
feature MOTOR_STOP
feature FAILSAFE
feature SUPEREXPO_RATES



map
map AETR1234

set mid_rc = 1500
set min_check = 1100
set max_check = 1900
set rssi_channel = 0
set rssi_scale = 30
set rssi_ppm_invert = OFF
set input_filtering_mode = OFF
set roll_yaw_cam_mix_degrees = 0
set max_aux_channels = 6
set debug_mode = NONE
set min_throttle = 1170
set max_throttle = 1980
set min_command = 1000
set anti_desync_power_step = 0
set servo_center_pulse = 1500
set 3d_deadband_low = 1406
set 3d_deadband_high = 1514
set 3d_neutral = 1460
set 3d_deadband_throttle = 50
set unsynced_fast_pwm = OFF
set fast_pwm_protocol = MULTISHOT
set motor_pwm_rate = 400
set servo_pwm_rate = 50
set disarm_kill_switch = ON
set gyro_cal_on_first_arm = OFF
set auto_disarm_delay = 5
set small_angle = 25
set fixedwing_althold_dir = 1
set reboot_character = 82
set serialrx_provider = SBUS
set sbus_inversion = ON
set spektrum_sat_bind = 0
set spektrum_sat_bind_autoreset = 1
set telemetry_switch = OFF
set telemetry_inversion = ON
set frsky_default_lattitude = 0.000
set frsky_default_longitude = 0.000
set frsky_coordinates_format = 0
set frsky_unit = IMPERIAL
set frsky_vfas_precision = 0
set frsky_vfas_cell_voltage = OFF
set hott_alarm_sound_interval = 5
set battery_capacity = 0
set vbat_scale = 110
set vbat_max_cell_voltage = 43
set vbat_min_cell_voltage = 33
set vbat_warning_cell_voltage = 35
set vbat_hysteresis = 1
set vbat_pid_compensation = OFF
set current_meter_scale = 400
set current_meter_offset = 0
set multiwii_current_meter_output = OFF
set current_meter_type = ADC
set align_gyro = DEFAULT
set align_acc = DEFAULT
set align_mag = DEFAULT
set align_board_roll = 0
set align_board_pitch = 0
set align_board_yaw = 0
set max_angle_inclination = 700
set gyro_lpf = OFF
set gyro_sync_denom = 1
set gyro_lowpass = 100
set moron_threshold = 32
set imu_dcm_kp = 2500
set imu_dcm_ki = 0

set yaw_p_limit = 500
set dterm_lowpass = 50
set dynamic_iterm = ON
set iterm_ignore_threshold = 200
set yaw_iterm_ignore_threshold = 35
set yaw_lowpass = 80
set pid_controller = LUX
set p_pitch = 58
set i_pitch = 28
set d_pitch = 23
set p_roll = 48
set i_roll = 29
set d_roll = 22
set p_yaw = 86
set i_yaw = 43
set d_yaw = 14
set p_alt = 50
set i_alt = 0
set d_alt = 0
set p_level = 30
set i_level = 50
set d_level = 100
set p_vel = 55
set i_vel = 55
set d_vel = 75
rateprofile 0

rateprofile
rateprofile 0

set rc_rate = 120
set rc_rate_yaw = 100
set rc_expo = 2
set rc_yaw_expo = 10
set thr_mid = 50
set thr_expo = 0
set roll_rate = 70
set pitch_rate = 70
set yaw_rate = 70
set tpa_rate = 20
set tpa_breakpoint = 1650
