Frigidaire Washer No High-Speed Spin Control Board Swap & Belt Replacement FRFW3700LW0 137005005(NH)

Описание: My Electrolux / Frigidaire FRFW3700LW0 (or just FRFW3700L) front-loading washer stopped going into high-speed spin. This is the same machine on which I removed, explained and replaced the door-latch in this video    • How To Test Or Bypass Frigidaire/Electrolu...   a year ago. Well, not it's not the door latch, it's the control board, so I guess I'd better go in and replace it. Along the way I mistakenly pull out the MOTOR control board, because I am an idiot. I also replace the main drive belt, the water inlet filters, and put the fear into my long-suffering wife. Enjoy.

The washer FRFW3700LW0
The "User Control & Display Board" 137005005 or 137005005NH (I found out the difference!)
The Motor Control Board 5304504863
The Drive Belt 134051003

00:00 - Intro
02:23 - Getting Into The Back
05:25 - Removing The Back Panel
06:22 - Removing The Motor Control Board 5304504863
08:13 - Opening The Motor Control Board Case & Wiring Harnesses
10:04 - Motor Control Board Tour
11:15 - Taking The Dryer Off The Washer
13:14 - Removing The User Control & Display Board 137005005
16:19 - Remove Door Switch 1317632 / Testing Door Wiring
21:09 - UI Board Tour & Diagnosis
23:13 - 137005000 vs 137005000NH Part Numbers & Ordering
24:24 - Reassembly
25:09 - Removing Water Inlet Water Filters
25:30 - Does it work? Using Diagnostic Mode To Pre-Test
26:50 - Replacing The Drive Belt 134051003
29:13 - Putting The Washer Back On Top Of The Dryer
30:08 - Aneurysm Hose Replacement
30:30 - Costs & Close
