Mastering DNV Plate Buckling Checks in SDC for Ansys: A Step-by-Step Guide

Описание: 📝In this step-by-step tutorial, you’ll learn how to perform a DNV plate buckling check using SDC Verifier within Ansys. We guide you through the process of launching SDC Verifier, loading materials and FEM data from an Ansys model, and selecting the relevant standards. You'll see how to set up and run calculations, recognize plates, and configure essential settings to ensure accurate results.

The tutorial also covers essential verification steps, like assigning missing material properties and visualizing results through criteria plots. By the end, you'll know how to add tables summarizing the check outcomes, helping you quickly assess whether sections pass the specified criteria.

Why Watch:

✔️Get a clear, guided walkthrough on running DNV plate buckling checks
✔️See how SDC Verifier integrates seamlessly with Ansys for efficient structural analysis
✔️Learn to visualize and interpret your results for better engineering decisions

✅ Subscribe for more in-depth tutorials on FEA, structural verification, and engineering standards.
👍 Like the video if it enhanced your workflow.
💬 Leave a comment with any questions or suggestions.

🌐 Visit our website to know more: https://bit.ly/3NKqVhF
https://bit.ly/3YhC1j2

Follow us on social media for updates:   / sdcverifier
  / sdcverifier

00:00 - Introduction: Starting the plate buckling check tutorial in SDC Verifier and Ansys
00:19 - Launching Ansys Mechanical and loading materials and FEM data
01:16 - Verifying the model calculation and setting up the standard
02:18 - Recognizing plates with the Panel Finder and previewing sections
03:29 - Adding a standard with checks and previewing results
03:47 - Setting up plot settings and generating a plot for the buckling factor under gravity loading
04:17 - Displaying plot results in Ansys Mechanical
04:40 - Summary of the tutorial; invitation to contact for engineering support
