DJI Matrice 200 Series Introducing (M200, M210, M210-RTK)

Описание: DJI Matrice 200 Series Introducing (M200, M210, M210-RTK)

DJI Matrice M200
AIRCRAFT
Model M200
Package Dimensions 31.1×15.4×11.4inch (790×390×290mm)
Dimensions (unfolded) 28.2×8.7×9.3 inch (716×220×236 mm)
Dimensions (folded) 34.9×34.6×14.9 inch (887×880×378 mm)
Folding Method Folded Inward
Diagonal Wheelbase 25.3 inch (643 mm)
Number of Batteries 2
Weight (TB50) Approx. 3.80 kg
Weight (TB55) Approx. 4.53 kg
Max Takeoff Weight 6.14KG
Max Payload (2 TB50) Approx.2.34kg (with two standard batteries )
Max Payload (2 TB55) Approx.1.61kg (with two standard batteries )
Hovering Accuracy (P-mode with GPS) Vertical: ±1.64 feet (0.5m) or ±0.33 feet (0.1m, Downward Vision System enabled)
Horizontal: ±4.92 feet (1.5m) or ±0.98 feet (0.3m.Downward Vision System enabled)
Max Angular Velocity Pitch: 300° /s；Yaw: 150° /s
Max Pitch Angle P Mode: 35°（Forward Vision System enabled: 25°）； A Mode: 35°；S Mode: 35°
Max Ascent Speed 16.4 ft/s (5 m/s)
Max Descent Speed Vertical: 9.8 ft/s (3 m/s)
Max Speed S Mode 23m/s P Mode 17m/s A Mode 23m/s
Max Service Ceiling Above Sea Level 1.55 mi (2500 m)
Max Wind Resistance 32.8 ft/s (10 m/s)
Max Flight Time(No Payload, with TB50) 27min
Max Flight Time(No Payload, with TB55) 38min
Max Flight Time(Full Payload, with TB50) 13min
Max Flight Time(Full Payload, with TB55) 24min
Motor Model DJI 3515
Propeller Model 1760S
Retractable Landing Gear Standard
Operating Temperature -4° to 113° F (-20° to 45° C)
IP Rating IP43

GIMBAL INSTALLATION
Downward Gimbal Mount Supported
Upward Gimbal Mount Not Supported
Downward Dual Gimbal Not Supported

BATTERY (STANDARD)
Model TB50
Capacity 4280 mAh
Voltage 22.8V
Battery Type LiPo 6S
Energy 97.58 Wh
Net Weight Approx. 520g
Operating Temperature -4° to 113° F (-20° to 45° C)
Storage Temperature Less than 3 months: -4° to 113° F (-20° to 45° C)
More than 3 months: 72° to 82° F (22° to 28° C)
Charging Temperature 41° to 104° F (5° to 40° C)
Max Charging Power 180 W
CHARGER

Model IN2C180
Voltage 26.1 V
Rated Power 180 W

FORWARD VISION SYSTEM
Obstacle Sensing Range 2.3-98.4 feet (0.7-30 m)
FOV Horizontal 60°，Vertical 54°
Operating Environment Surfaces with clear patterns and adequate lighting (....15 lux)
DOWNWARD VISION SYSTEM

Velocity Range ....32.8 ft/s (10 m/s) at the height of 6.56 feet (2 m)
Altitude Range .....32.8 feet (10 m)
Operating Range ....32.8 feet (10 m)
Operating Environment Surfaces with clear patterns and adequate lighting (....15 lux)
Ultrasonic Sensor Operating Range 0.33-16.4 feet (10-500 cm)
Ultrasonic Sensor Operating Environment Non-absorbing material, rigid surface (thick indoor carpeting will reduce performance)

.....................................................................................................................
