Slitter: Gary, Model 4000, 72" x 6" Arbor, 12 Ga. Cap., 15 HP, 1975
Автор: AltmanMachinery
Загружено: 2013-01-15
Просмотров: 468
Описание:
(1) Used 72" GARY Sheet Slitter,
Model 4000-72, S/N 239, New 1975
Specifications:
Maximum Sheet Width: 73-7/8"
Knife Arbor Diameter: 6"
Knife Dimensions: 9" O.D. x 1.5" Thickness
Cutting Capacity: 21 Cuts in 20 Ga.
12 Cuts in 18 Ga.
7 Cuts in 16 Ga.
5 Cuts in 14 Ga.
2 Cuts in 12 Ga.
Minimum Trim Cut -- Gage Side: 3/8"
Off-Gage Side: 1/8"
Minimum Intermediate Cut: 3"
Pass Line Height: 42"
Speed (Inf. Variable): 100' -- 300' / Min.
Motor: 10 HP 3/60
Overall Dimensions (Approx.): 102" L-R x 55" F-B
Weight (Est.): 5200 Lbs.
Equipped With:
(18) Knives
Automatic Material Feed Control
Penetration Adjustment Using Twin Jack Screws (in 0.001" Increments)
Feed Table
F.O.B. Chicago, IL
