In the CLASSIC 102i, nothing has been left to chance, starting from the dual mono power supply and circuitry to the actual core, where every amplification section is dual, including the innovative volume control that uses two separate stages for each channel on a digitally controlled MOSFET array. Moreover, due to its balanced nature, even the single ended line inputs are fully converted to balanced, including the PHONO RIAA stage. Simply put, you won't hear a more dynamic and transparent preamplifier than this one.
The volume control section, a stage not to be underestimated.
TECHNICAL FEATURES
Natively balanced dual mono integrated amplifier
RMS power per channel, both channels driven @1Khz
100W at 8 ohms
180W at 4 ohms
290W at 2 ohms
EIA power per channel, both channels driven / 20Khz
190W @8 ohm
300W into 4 ohms
450W into 2 ohms
THD + N - A-weighted - 0.003% at full power into 8 ohms
Inputs
1 balanced input via XLR
3 line inputs
1 RIAA MM phono input
1 selectable AMP-IN
outputs
1 pair of RCA PRE-OUTs
1 pair of 6 mm binding posts
Input impedance
47 Kohm via XLR, 22 Kohm via RCA
Slew/rate
35 V/uS
Frequency response
20 Hz to 40 Khz +/- 0.2 db
Phono input
MM - 47Khom - 41 db gain
DAC Section
USB - 384 Khz pcm - DSD256 in Dop mode / native DSD 512
COAX
Optical
Dimensions 38 -- x 42 x 11 cm. (D x W x H)
Weight 15 kg
OPTIONAL DISPLAY COLOURS
White, yellow, green, blue
REMOTE CONTROL INCLUDED
