SWR Elast Poly V Belt | Elast Belt | Power Transmission Elastic Belt

Описание: The SWR® is a power transmission elastic belt featuring multiple longitudinal ribs. Our SWR® belt transfers power from the roller motor to all conveyor belt rollers.

These belts have specifically developed for roller conveyors and have capable of transporting parcels weighing from 1 kg to 2 tonnes.

Belt Structure:
The polyamide elastic cord of the SWR® has outstanding mechanical properties. It can withstand temperatures of more than 80 Deg C

SWR has developed a standard compound and a “cold resistance rubber compound capable of withstanding temperatures down to -30 Deg C . It works equally well with straight or curved conveyors.
Technical Features:
 Longitudinal grooves with two to eight ribs.
 Resistant to temperatures from -30 to 80 Deg. C
 Electrically conductive to ISO 1813
 Suitable for tropical climates
 Suitable for fixed centre distances
 Suitable for counter bending
 Reduced noise level
 Capable of smoothly transporting packages weighing from one kilogram to two tons
 Increases parcel transport speeds of up to 3 m/s.
 The elasticity of the SWR® allows it to absorb shocks, unlike chains or synchronous belts.

Benefits:
• Cost-Effective
• Energy Efficiency
• Reliability
• Applications:
• The SWR® belt can also be installed on pallet conveyors. It can also be adapted to suit many special applications.
• Multi-level conveyors: Efficient use possible at an angle of 10% maximum.
• Accumulation: Accumulation rollers with grooved profiles are now available for use with the Swr®.
• Curves: minimum interior radius 800 mm and maximum angle roller to roller 5°.
