Azure Network Security Group Design
You can use an Azure network security group to filter network traffic to and from Azure resources in an Azure virtual network. A network security group contains security rules that allow or deny inbound network traffic to, or outbound network traffic from, several types of Azure resources. For each rule, you can specify source and destination, port, and protocol.

A network security group contains zero, or as many rules as desired, within Azure subscription limits.

Each rule specifies

Priority: A number between 100 and 4096. Rules are processed in priority order, with lower numbers processed before higher numbers, because lower numbers have higher priority. Once traffic matches a rule, processing stops. As a result, any rules that exist with lower priorities (higher numbers) that have the same attributes as rules with higher priorities are not processed.

Source or destination
Any, or an individual IP address, classless inter-domain routing (CIDR) block (10.0.0.0/24, for example), service tag, or application security group. If you specify an address for an Azure resource, specify the private IP address assigned to the resource. Network security groups are processed after Azure translates a public IP address to a private IP address for inbound traffic, and before Azure translates a private IP address to a public IP address for outbound traffic. . Specifying a range, a service tag, or application security group, enables you to create fewer security rules. The ability to specify multiple individual IP addresses and ranges (you cannot specify multiple service tags or application groups) in a rule is referred to as augmented security rules. Augmented security rules can only be created in network security groups created through the Resource Manager deployment model. You cannot specify multiple IP addresses and IP address ranges in network security groups created through the classic deployment model.

Protocol - TCP, UDP, ICMP or Any.

Direction - Whether the rule applies to inbound, or outbound traffic.
Port range - You can specify an individual or range of ports. For example, you could specify 80 or 10000-10005. Specifying ranges enables you to create fewer security rules. Augmented security rules can only be created in network security groups created through the Resource Manager deployment model. You cannot specify multiple ports or port ranges in the same security rule in network security groups created through the classic deployment model.

Action - Allow or deny

Network security group security rules are evaluated by priority using the 5-tuple information (source, source port, destination, destination port, and protocol) to allow or deny the traffic. You may not create two security rules with the same priority and direction. A flow record is created for existing connections. Communication is allowed or denied based on the connection state of the flow record. The flow record allows a network security group to be stateful. If you specify an outbound security rule to any address over port 80, for example, it's not necessary to specify an inbound security rule for the response to the outbound traffic. You only need to specify an inbound security rule if communication is initiated externally. The opposite is also true. If inbound traffic is allowed over a port, it's not necessary to specify an outbound security rule to respond to traffic over the port.

Existing connections may not be interrupted when you remove a security rule that enabled the flow. Traffic flows are interrupted when connections are stopped and no traffic is flowing in either direction, for at least a few minutes.

Augmented security rules
Augmented security rules simplify security definition for virtual networks, allowing you to define larger and complex network security policies, with fewer rules. You can combine multiple ports and multiple explicit IP addresses and ranges into a single, easily understood security rule. Use augmented rules in the source, destination, and port fields of a rule. To simplify maintenance of your security rule definition, combine augmented security rules with service tags or application security groups. There are limits to the number of addresses, ranges, and ports that you can specify in a rule.

Application security groups
Application security groups enable you to configure network security as a natural extension of an application's structure, allowing you to group virtual machines and define network security policies based on those groups.
