EasyEDA PCB of my MAX SSB 210 IF AMP A (An update)
Автор: Circuit6040
Загружено: 2026-01-31
Просмотров: 111
Описание:
Here is a PCB I designed in EasyEDA of my MAX-SSB IF TIA module # 210.
This is an update to my original video (which I have deleted). In this new video I have made changes to the PCB to prevent shorting out the RF input and output lines as they go under the SMA connector flange. In this new design I have routed the traces on the other side of the PCB as they go under the SMA.
Please note that I have not yet had the PCB produced so no actual real world testing has been done and that the design is experimental and for entertainment purposes only.
The schematic and webpage are here:
http://www.remmepark.com/circuit6040/...
The EasyDEA (.epri) file for this PCB is here:
http://www.remmepark.com/circuit6040/...
The EasyDEA (.epro) file for this PCB is here:
http://www.remmepark.com/circuit6040/...
