Simple Ryobi RM480e Battery Replacement in 15 Minutes – Single 48v Lithium w/ LiFePO4 Charger!
Автор: 36x
Загружено: 2025-08-28
Просмотров: 2599
Описание:
The original version of this video featuring the stock charger is here: • Simple Ryobi RM480e Battery Replacement in...
Following the simple steps below, we were easily able to convert our failing electric riding lawnmower into one which:
Requires no modifications to the factory wiring of our Ryobi mower
Cuts our 1.25 acre yard twice before needing a recharge (at around 30%)
Can be charged with both the stock charger OR the DCHouse LiFePO4 charger (you choose)
Charges at .25% per minute (for example, from 25% to 100% in only 4 hours)
Has an advanced Bluetooth battery management system that protects our investment
No longer needs to be plugged in when not in use
Replaces 4 heavy lead batteries with a single lithium battery protected by a 3 year warranty
STEPS: (Similar for 48v Zero Turn mowers such at ZT480)
0:00 INTRODUCTION
0:25 OPEN BATTERY ACCESS PANEL
0:57 DISCONNECT BATTERY
1:29 REMOVE MAIN BATTERY BOLT
1:59 REMOVE BACK COVER
2:18 REMOVE BATTERY TRAY BOLTS
2:54 DISCONNECT CHARGER LOCKOUT WIRE
3:29 SLIDE OUT BATTERY TRAY
5:06 DISCONNECT TERMINALS AND REMOVE BATTERIES
6:28 VACUUM OUT MOWER AND PREPARE IT FOR REASSEMBLY
7:01 ZIP-TIE (7.75") 2X4 SPACER TO TRAY
7:10 SECURE BATTERY TO TRAY USING LARGE ZIP-TIES
7:38 SECURE BOTH DCHOUSE AND RYOBI TERMINALS TO BATTERY
9:51 SLIDE BATTERY TRAY INTO MOWER HOUSING
10:00 BOLT DOWN BATTERY TRAY
10:16 RECONNECT CHARGER LOCKOUT CABLE
10:43 CHECK VOLTAGE BEFORE CONNECTING BATTERY
10:56 PLUG BATTERY INTO MOWER
11:09 CHECK VOLTAGE AT CHARGING PORT
11:22 RUN DCHOUSE CHARGE PORT THROUGH SEAT COVER
11:53 CONNECT BATTERY USING BLUETOOTH APP
12:02 PLUG IN CHARGER AND BRING BATTERY TO 100%
13:27 CHECK THE CHARGING STATUS IN THE APP
14:21 UNPLUG MOWER AND TEST THAT ALL IS WORKING
15:26 CLOSE UP THE BACK PANEL AND YOU ARE DONE!
As an Amazon Associate we earn a small commission, at no cost to you, through Amazon links.
Battery Options
DCHouse 100AH Battery (includes charger): https://amzn.to/3ROzom8
DCHouse 100AH Battery (premium "metal case" model): https://amzn.to/44UwjYI
DCHouse 48v LiFePO4 Charger (standalone): https://amzn.to/464k6kP
The 50AH battery is also an option if you have under 1 acre:
DCHouse 50AH Battery (includes charger): https://amzn.to/3GM1EDB
Materials Used
36" Zip Ties: https://amzn.to/4lz2i6B
Klein Zip-Tie Tightener: https://amzn.to/4iMzIfU
Two milk crates to support battery tray: https://amzn.to/3RKPI7n
DCHouse LiFePO4 Charger: https://shorturl.at/kBfg1
Tools Used
Dewalt Impact Driver: https://amzn.to/4iRbMIq
Socket Adapter: https://amzn.to/4k1LSCL
10, 12, 13 MM sockets: https://amzn.to/3YwygqT
12MM wrench: https://amzn.to/44wyz7j
Phillips Screwdriver: https://amzn.to/4d2zb8t
T30 Torx for four back screws: https://amzn.to/44kX1tX
Digital Multi-meter: https://amzn.to/3EFjwiS
Our Choice of Charger
This is a follow up video to our first video which uses the stock charger. • Simple Ryobi RM480e Battery Replacement in...
The intention is to show how LiFePO4 chargers can be used in this conversion without having to modify the stock circuitry of your mower.
You get to use the existing charger wiring as-is, with zero modifications.
The DCHouse charger is on par to the Ryobi stock chargers in quality.
Our Choice of Battery (DCHouse 48V 100Ah)
We chose to go with the DCHouse battery because of price and positive feedback in the group. It seemed to be a new arrival to this battery form factor and people in the group were speaking highly of its BMS/Bluetooth app. We chose 100 AH because we have a 1.25 acre plot and wanted to have more than enough coverage. Here is a great write-up on the DCHouse BMS:
https://rb.gy/csfdyn
https://tinyurl.com/2mjkdhyj
Battery Meter
We chose not to add any battery meter (including the one that came with the battery). The Bluetooth app that came with the battery was more than enough for our purposes. At any time we can take out our phone and see a realtime summary of the state of our battery and we always have plenty of capacity for our yard.
Here is the manual to the Bluetooth app: https://tinyurl.com/2mjkdhyj
Overall Outcome
We love our newly upgraded mower, all of the changes are for the better. The main problem of the battery running low during use are now gone. The performance is better during the mow, it is faster and never bogs down on hills (and our yard has many). Now we charge it to 100% and then use it until it gets down to 20-30%, charge it over night and then unplug it after the charge is complete. In addition, we no longer have to keep it plugged in when not in use.
Related Links
How Your 48v Battery Can Power Your Home in Emergencies: https://tinyurl.com/mt7a7mcs
Greg Handley's Facebook Group: / ryobi48vmowers
Music: https://tinyurl.com/yc76pa4h
Supporting the Channel
Hitting Like/Subscribe will help others find this video!
You can also support us here: https://ko-fi.com/support36x
May God Bless You.
