Walk Around: 36K Gooseneck Flatbed Equipment Trailer | Texas Pride Trailers

Описание: Our Texas Pride 36K Gooseneck Flatbed Equipment Trailer is loaded with impressive standard features. Our trailers are American made and built by hand in Texas. See the full specs and options below. Enjoy Factory-Direct savings by calling (936) 209-7171. We also offer fast and easy financing.

Visit the full product page:
https://txpt.link/30fbgnyt
Have questions or ready to make a purchase? Contact us at (936) 209-7171

PRICING
Standard trailer with 5’ self cleaning dovetail and fold over deck level ramps
8½' x 20' + 5' (25' overall deck length) $13,795
8½' x 25' + 5' (30' overall deck length) $14,295
8½' x 27' + 5' (32' overall deck length) $14,495
8½' x 30' + 5' (35' overall deck length) $14,795
8½' x 35' + 5' (40' overall deck length) $15,295
8½' x 40' + 5' (45' overall deck length) $15,795

All flat deck trailer with 8' slide-in ramps (no dovetail)
8½' x 25' (25' overall deck length) $13,795
8½' x 30' (30' overall deck length) $14,295
8½' x 32' (32' overall deck length) $14,495
8½' x 35' (35' overall deck length) $14,795
8½' x 40' (40' overall deck length) $15,295
8½' x 45' (45' overall deck length) $15,795
*Add $500 fee for pick up at our stores in North TX, MO and TN.
*Trailers are available from 20' to 45' long in 1 ft increments ($100/ft)

SPECIFICATIONS
G.V.W.R.: 36,000 lbs
Empty Trailer Weight: 8,900 lbs (20' trailer with no additional options)
Net Payload Capacity: 27,100 lbs (20' trailer with no additional options)
Axles: Triple tandem 12,000 lb 8 lug (electric brakes on all axles)
Suspension: Heavy duty slipper spring
Brakes: All wheel electric brakes on all axles (12" x 5" brake shoe)
Tires: New 16" ST235/80R16 10ply radial LRE (3,520lbs ea)
Wheels: 16"x6" eight hole white or silver (based on stock)
Main Frame: 14" I-Beam
Gooseneck Risers: 14" I-Beam
Gooseneck Beams: 14" I-Beam
Cross Members: 4" channel on 16" centers (pierced thru the frame)
Outer Deck frame: 6" channel
Deck Length: 20' to 45'
Deck width: 102" overall
Deck height: Approximately 34"
Flooring: 2" treated pine (screwed down)
Tie downs: Stake pockets (on 24" centers) with rub rail (2" tall x 3/8" thick)
Storage: Front locking chain box with lid built into gooseneck
Dovetail: 5' self cleaning (n/a on all flat deck models)
Ramps: 8’ slide in (flat deck models) or 5’ fold over deck level spring assisted (dovetail models)
Coupler: 3" Coupler
Jacks: Dual 12,000 lb drop leg jacks (spring loaded)
Lights: All flush mount or recessed lifetime LED lighting
Wiring: USA made sealed modular wiring harness
Safety Chains: Two heavy duty safety chains
Safety Features: All required DOT lighting, safety chains, reflective tape and emergency break-a-way switch
Finish: Fully primed and painted with 2 coats of automotive grade acrylic enamel
Torque Tube: Torque Tube (prevents trailer twist)

ADDITIONAL OPTIONS
16" 10ply mounted spare tire and rim: $150
16" 14ply mounted spare tire and rim: $200
17.5" 16ply mounted spare tire and wheel: $275
Upgrade from 10ply to 14ply tires: $75/ea ($900 total)
Upgrade from 10ply to 16ply tires: $150/ea ($1800 total)
Upgrade to triple 12,000 lb electric over hydraulic disc brakes: $2,500
Mammoth Ramp upgrade: $400
Third ramp: $200
Pop-up: $250 (on dovetail models only)
Slide rail with slide ratchets and 4" x 30' straps: $600 ($40 per ratchet and strap as needed)
Pipe spools between the stake pockets: $150
Upgrade to cross members on 12" centers: $250
Winch plate: $100
8k Warn winch installed with battery and charger: $1,250
Chain rack: $200
6' x 8' deck up on gooseneck: $500
97" long under body dunnage box: $500/ea
18"x18"x36" under body locking tool box: $400/ea
Receiver tube for hitch bar on back of trailer: $75
7 way plug on back of trailer: $75
Stock white, red, blue, orange, green or yellow paint: $350
Hutch Suspension: $1,700
Upgrade to air ride suspension: $11,000
Upgrade to air ride suspension with lift axle: $12,500
A pair of 9' aluminum loading ramps for non-dovetail trailer: $900
King pin adapter for gooseneck hitch: $150

With over twenty years of experience building high-quality trailers, Texas Pride has become one of the largest trailer manufacturers in the country. With 6 nationwide locations, over 200 employees, 250,000 square feet of manufacturing space, and over 7 different trailer lines, you can be assured we have the experience and know-how to build the right trailer for you. As large as we’ve grown we are still a family-owned and operated company, which means service is still of the utmost importance to us. We manufacture, sell direct to our customers, and handle service after the sale all within the same company. This saves you money and makes sure we are there for you after your purchase. We look forward to hearing from you.

Texas Pride... G'tcha One!
