ORD_CC_Culvert
Автор: BentleyCivil2
Загружено: 2022-04-28
Просмотров: 878
Описание:
Description of use of a civil cell to model a culvert wingwalls and terrain model to enable corridor clipping.
Table of Contents:
00:00 - Introduction
00:18 - Civil Cell Parameters
01:11 - Corridor Geometry linking
02:33 - Culvert Cell placement
03:51 - Corridor target alisaing
05:08 - Adding Key Stations
06:20 - Clipped corridor
06:39 - return / update of culvert fiile
07:31 - Culvert Width
08:15 - Culcert Height
08:38 - Headwall thickness
09:16 - MAin Road Side Slopes
09:26 - Corridor Side Slopes
10:25 - Terrain model for corridor target alias
10:32 - Terrain models for wing walls
10:36 - Wong wall geometry
11:58 - Editing the culverting location
12:56 - Adjusting headwall location
