Arrow XT™ Pumper – Port Allegany, PA

Описание: Star Hose Company No.1 in #PortAlleganyPA has their #ArrowXT #Pumper at #FDIC2022! The apparatus is equipped with 9 preconnected handlines. For easy cleaning, the department chose vinyl seats and diamond plate flooring. The pump panel is equipped with a garden hose outlet which is plumbed through a heat exchanger which draws heat from the engine to warm the water for decontamination after fire responses. All compartments include a drying system for wet equipment. At the rear of the apparatus an outlet for the Firecom system was added so when backing up the apparatus, an officer at the rear can communicate more effectively with the driver.

CHASSIS
Chassis: 67” Arrow XT cab
Seating capacity: 6
Overall height: 10’ 1”
Overall length: 30’ 8.75”
GVW Rating: 53,800 lb
Safety: Side Roll and Frontal Impact Protection
Front axle: #TAK4 Independent Front Suspension, 22,800 lb
Rear axle: Dana S30-190, 31,000 lb
Engine: Cummins X15, 605 hp, 1850 torque
Electrical System: Command Zone™ Advanced Electronics System

BODY
Material: Stainless Steel
Shelving: Adjustable, up to 500 lb
Doors: Lap
Pump: Waterous, 2000 gpm
Tank: 1000-gallon
Pump Panel: 48”

Job Number: 36413
Dealership: Glick Fire Equipment Co.
