How to use ezcap324B PCIE Video Capture Card LIVE GAMER RAW PCIe 2160p30, 1080p120 Live Streaming

Описание: Features:
2160p30, 1080p120 and 1440p60 HDMI input and pass-through.
1080p120, 2160p30 and 1440p60 recording. RGB real color video format up to 1080p30.
Latency less than 50ms.
UVC standard, manual driver installation is not needed. Supports most of third party video capture softwares.
PCIe Gen2 super fast speed.
With Line in and Line out port.
With colorful breathing indicator.

Specifications:

Interface: PCIe Gen2 X1
Video Input: HDMI® 1.4 enabled
Audio Input: HDMI, Line In (3.5mm TRS)
Video Output: HDMI 1.4
Audio Output: HDMI, Line Out (3.5mm TRS)
Max. Pass-Through: 2160p30, 1440p60, 1080p120
Max. Recording: 1080p120, 2160p30, 1440p60
Supported Resolution: 2160p, 1440p, 1080p, 720p
Output Video Format: YUY2, NV12, RGB
Recording Resolution and Max FPS: 3840x2160 - NV12/30; 2560x1440 - NV12/60, YUY/50; 1920x1080 - NV12/120, YUY/60, XRGB/30; 1280x720 - NV12/60, YUY/60, XRGB/60.
Status Indicator: RED-power, BLUE-HDMI input, Mixing Slow Flashing-device running.

System Requirement:

Windows 10 x 64, PCI-E X1 slot
For 4Kp30 or 1080p120 recording:Intel Core i5-6XXX / AMD, Ryzen 3 XXX or above, NVIDIA GTX 1060 / AMD RX 5700 or above, 8 GB RAM.
For 1080p60 recording:Intel Core i7-3770 recommended, NVIDIA GeForce GTX 650 / AMD Radeon R7 250X or above, 4 GB RAM.
Mac Pro, Mac OS High Sierra 10.15 and above, PCI-E X1 slot

Package Contents:
ezcap324 Live Gamer RAW, Manual

Dimensions:151 x 121 x 22 mm
