CTC 3D Printer MKS Sbase Board Replacement

Описание: After having problems with inconsistent extrusion on my CTC 3D printer I found a problem on the Mightboard and decided to swap it out for an MKS Sbase board. In this video I show you how I installed the MKS Sbase V1.3 Board and how I wired it up.

**** You do this at your own risk and I take no responsibility for any damage that may occur ****

Please don't ask for my Simplify 3D fff profile I will not give this out. Thanks

▼▼▼ Parts Used ▼▼▼

MKS Sbase V1.3 & TFT 32 V4.0 Screen (aliexpress.com): https://tinyurl.com/y5h75x43
MKS Sbase V1.3 (aliexpress.com): https://tinyurl.com/y5hwq5kw
MKS TFT32 V4.0 (aliexpress.com): https://tinyurl.com/y5sp7q95
FAN (Amazon): https://tinyurl.com/yxohnfyp
Mos Driver Module (Banggood.com): https://tinyurl.com/y6mre7aj
JST connectors (eBay): https://tinyurl.com/yykaymvk
Wire cutters and crimping tool (Amazon): https://tinyurl.com/yyzmzdo9
Hotend (eBay): https://tinyurl.com/yyzfyd8h

********************

Smoothieboard site: http://smoothieware.org/smoothieboard

********************

Thingiverse files:
120mm Fan Mount: https://www.thingiverse.com/thing:362...
MKS TFT32 Screen Mount: https://www.thingiverse.com/thing:352...
Filament Oiler: https://www.thingiverse.com/thing:351...
