Canon C500 Mark II - Tech Talk RODRRICO

Описание: Rodrrico discusses the new Canon EOS C500 Mark II 5.9K Full-Frame Camera. The C500 mk ii is the latest Cinema EOS Camera in the long line of Canon Cinema EOS cameras.

It features a full-frame CMOS sensor with an effective 18.69MP resolution. This allows it to feature a 5.9K output in full frame, and crop (window) the sensor for Super 35 and Super 16 frame sizes while maintaining a high resolution. The C500 Mark II comes with a Canon EF mount and features an interchangeable lens mount system, allowing you to swap out the mount in the field for an optional Cinema Locking EF or PL mount, thus greatly expanding the amount of glass you can use with the camera. The sensor features over 15 stops of dynamic range and Dual Pixel autofocus support, and the camera uses a DIG!C DV 7 chip for image processing.

The camera internally records raw using the Canon Cinema RAW Light codec in 12- or 10-bit, or you can capture using the XF-AVC codec in 10-bit. Internal recording is done to CFexpress cards via two CFexpress card slots. 8-bit proxy recording in the XF-AVC codes, as well as JPEGs, can be captured onto an SD card via the built-in SD card slot. Supporting a variety of gamma settings including Canon Log 2 and Log 3, as well as supporting a variety of color gamuts including Cinema BT.2020, DCI-P3, and legacy BT.709. LUT importing is supported of course. The camera supports four channels of 24-bit, 48 kHz linear PCM audio recording.

KEY SPECS:
Image Sensor, CMOS Full Frame 5.9k (6062 x 3432) 20.8MP
Aspect 17:9 - the same sensor as the C700.
Anamorphic / Spyrical Lens Support
Crop Factor Super 35mm / Super 16mm
ISO 160 - 25,600 Native
ISO 100 - 102,400 Expanded10 Stop ND
EF or PL Lens adaption (user modification)
2 x CF Express slots
1 x SD UHS-II slot
Canon Dual Pixel AF (autofocus)

INTERNAL RECORDING:
Camera RAW Light 10-Bit or 12-Bit 4k
XF-AVC 4,2,2 10-Bit
XF-AVC 4,2,0 8-Bit
Gamma: Clog 2, Clog 3, HDR-HLG, HRD-PQ, Normal 1, Wide DR
4 Channel 24Bit 48Khz LPCM Audio

INTERFACE:
1 x BNC (12G-SDI) Output
1 x BNC (3G-SDI) Monitor Output
1 x HDMI Output
1 x 1/8” / 3.5mm Stereo Mic Level Input
2 x XLR Mic Input
1 x 1/8” / 3.5mm Stereo Headphone Output
1 x BNC Timecode In/Out

MONITOR:
4.3” LCD
2.76Million Dots
NO EVF Included

POWER:
BP-A compatible

GENERAL:
Weight 3.9lb / 1.77Kg
