Endorfy ARX 500 Case - MAXIMUM airflow!

Описание: Just a couple of months ago we did a sponsored build with a brand new case from Endorfy, The ARX 700 was Endorfy’s first case to be designed and built entirely in-house, it came with mesh, five 140mm fans and a budget price tag. Well, Today I'm looking at the new Endorfy ARX 500 which has lots of the same features as the ARX 700, it comes in two different versions with or without RGB and it's more compact and cheaper. But is it as good? Let's find out.

We never offer affiliate links or take percentages of product sales. If we say the product is good or bad we mean it. Our Editor in chief wrote about why you should value this and how the industry is rife with fake reviews from 'influencers' - read here https://bit.ly/3pXzaw4

00:00 Start
00:55 Features
03:01 James thoughts / closer look / support
07:27 Side panel - cable management
08:40 PSU support / storage space
09:29 5 port PWN fan hub
09:55 Floor of case
10:53 Build hardware
12:19 Build timelapse
17:05 James thoughts on the build experience
19:16 Thermal/noise performance with high end system
20:34 Closing Thoughts

EU Price:
• ARX 500 Air – 99 EUR
• Arx 500 ARGB – 109 EUR

ARX 500 Air/ARGB Features:
• Spacious Interior that allows for Seven fans to be installed – 5 x 140mm Endorfy Strutus 140 PWM fans come pre-installed in the ARX 500 Air, 4 x 140mm ARGB fans in the ARGB case and regular Black fans in the ARX 500 Air.
• Both cases feature a built-in 5 port PWM fan controller and a 5 port 3-pin 5v ARGB Hub is also included with the ARGB model.
• Front and top panels are heavily ventilated with perforated steel ultrafine mesh panels that also act as a single-layer dust filter so they are less airflow restrictive compared with cases that have a secondary dust filter. Both panels are easily removable for cleaning.
• Tempered glass left-hand side panel.
• Compact ATX case measuring 486 x 228 x 429mm but allows for the installation of 360mm and 280mm radiators, as well as graphics cards up to 350mm long and CPU coolers up to 179mm tall.
• Front I/O Connectivity includes a single USB Type-C port, two USB Type-A ports, individual 3.5mm audio jacks for headphones and microphone, a power button and a reset button that can be repurposed as an ARGB control button.
Cooling support:
• Front – up to 3 x 120/140mm fans or up to 360mm radiator (120/240/280)
• Top – up to 2 x 120/140mmf ans or up to 280mm radiator (120/240)
• Rear – 120/140 fan/Radiator
• PSU Shroud – 2 x 120/140mm fans
• Max CPU cooler Height – 179mm
Hardware support:
• Motherboards support – ATX, Micro-ATX, Mini-ITX – (no EATX Support)
• 7 x Rear PCie expansion Slot cutouts
• Max GPU length – 350mm
• Max GPU height – N/A
• Max GPU Width – N/A
• PSU type – ATX up to 300mm long
Storage Support:
• 2.5” Drives – Total 6, 2 x PSU Shroud, 2 x Motherboard tray, 2 x Rear chassis frame
• 3.52 Drives – 1 x 2.5/3.5” combined mount chassis floor
Build Specification
• CPU – Amd Ryzen 9-7900X
• Motherboard – Gigabyte X670 Aorus Elite AX
• Graphics Card – Gigabyte RTX 4070Ti Gaming OC
• Memory – 32GB (2 x 16GB modules) Corsair Dominator Platinum DDR5-6000
• Storage – 1TB WD_Black SN850 PCIe Gen4 NVME NM.2 SSD
• CPU Cooler – Endorfy Navis F280 280mm AIO Liquid Cooler
• Power Supply – Endorfy Supremo FM5 Gold 1000W 80+ Gold Certified
• Case fans – Stock
• Chassis – Endorfy ARX 500 ARGB
• Operating System – Windows 11
