[Salome Meca Tutorial] Simulating glued contact in code aster
Автор: Cyprien Rusu
Загружено: 2018-03-08
Просмотров: 14386
Описание:
Here’s what you will learn in this video:
How to create the geometry for a 3D model
How to mesh it and create groups
How to assemble several mesh sets as one to facilitate the definition of your analysis
How to create a glued contact between 2 parts
How to check that it works and that you get correct results
*Note: You’ll remark righteously that I made a few mistakes during the modeling phase, but I decided not to edit this part to eventually leave the liberty to some developers watching to think about eventual improvements of the graphical interface… cough, cough
*Note 2: Yes, you need smaller mesh on the slave face!
If you like this video, could please help me by liking it? Thank you so much!
To leave a comment on the blog, here's the link:
http://feaforall.com/salome-meca-tuto...
