⚡BRILLIANT⚡System UpGrade⚡ Matches a Half-Wave 80m Dipole (TX comparisons from my QTH at 5 watt QRP)

Описание: The recent Upgrade is somewhat simple to build & easy
to add to this type of system.

The Electric Dipole has a lower Take off angle than the more classic dipole at less than 1/2 wave elevation though this working principle allows for easy manipulation of both the TOA and also the pattern/ directivity in general within a small physical space.

I will explore this further in due course.

This new development also means that I will be able to Upgrade my HF E field Electric Dipole Mobile system in the same way with a very small modification in the near future...
(Further increasing the ERP of that system).

I am so glad that I got out of bed to build this design upgrade after I woke up with the idea in my head.

Although I really wanted to roll over & go back to sleep,

I knew that if I decided to go back to sleep and leave it until the morning,
I actually would have forgotten the design concept.

There Truly is much more that we can do with Electromagnetism than I had previously assumed to be possible.

I feel very fortunate to be the one making these discoveries one after the other.

73 de VK3VKe ⚡🙏⚡

PS: If i have made typo errors,

please make allowances
as I have damaged my eyesight due to playing with high energy low powered RF
& didn't realise until the damage was done.

If you are viewing my channel for the first time,
please feel free to look back through my videos
to see an evolution taking place.

Cheerz from Crazy Ham ⚡🙏⚡

Side Note :

I will be playing with azimuthal directivity on a similar system in the future

I also plan to attempt to vary the Hop/skip propagation Distances utilizing a concept I have dreamt up based on varying the relative net E field potentials with respect to the remaining global surface areas
purely based on a conceptual take on rf propagation that differs a lot from our conventional take on this subject (Which I strongly disagree with anyhow).

Perhaps my idea will fail
or it may well work !

Wish me Luck...

73 de VK3VKe ⚡🙏⚡
