Walkera F210 Racing Drone Flight Test Review

Описание: This fast little racer quadcopter is very suitable for new FPV fliers. Yet, give it some pitch and watch it scream! You can even fly FPV in the dark with its IR camera. Find it here http://amzn.to/2nOlJLl

Pros
It's a stable flier, yet also very fast.
Seriously Pro Racing FC3 flight controller http://seriouslypro.com/files/SPRacin... Flight control board is configurable. But it is a good stable flier out of the box for new FPV fliers (not beginner fliers). PID's tweaking is not really required.
14.8V 1300mAh 40C 4S LiPo battery gives this quadcopter plenty of punch.
HD camera with low light level and IR capability. Quadcopter includes IR emitters on front for night FPV flying.
Includes Stabilized, Horizon (stabilized but without bank or pitch angle restrictions), and Full Acro modes (no stabilization, no angle restrictions). Stabilized mode is very gentle for beginner FPV fliers, yet allows very steep pitch for fast flying if desired.
Very good control and FPV video range (hundreds of meters).
Requires FAA registration as it is over 250 grams (It weighs 557 grams).
Body appears to be mostly carbon fiber construction, and should be resistant to crashes.

Cons
Somewhat pricey.
Camera does not include recording capability. There is no mount/platform provided for optional recording camera.
Appears to be very top heavy. Unsure of how this will handle in Acro mode?
Very flat sliding turns in stabilized mode. Applying roll to induce banking for tightened turns seems to have little to no effect.

And here is its flight demonstration.

Brand Name: Walkera
Item Name: F210 Racing Drone
Model: F210
Version: Devo7 Right Hand Throttle, Devo7 Left Hand Throttle and BNF Version

Aircraft:
Main Rotor Dia: 128mm
Overall Dimension: 182x182x103mm
Weight: 370g(Battery included) (but I weighed it, and it was closer to 557 grams with battery)
Remote Controller: DEVO 7
Receiver: DEVO-RX713
Main Controller: FCS-F210(F3)
Transmitter: TX5825(FCC)/TX5824(CE)
OSD: F210 OSD
Brushless Motor: WK-WS-28-014A(CW/CCW)KV2500
Brushless ESC: F210(CW/CCW)
Battery: 14.8V 1300mAh 40C 4S Li-PO
Flight Time: 8~9mins
Working environment: -10℃ ~ +40℃

Camera(700TVL):
Horizontal Resolution: 700TVL
System Commitee: PAL/NTSC
Video Out: 1.0Vp-p/75Ω
Power Input: DC 12V

TX5825(FCC)/TX5824(CE) Transmitter:
5.8G wireless:Image transmission
TX5825(FCC) Bind B section:4 channels
TX5824(CE) Bind B section:4 channels
TX5825(FCC) output power:≤200mW
TX5824(CE) output power:≤25mW

Features:
-Night Sight HD Camera
-Centralized Control System Design
-SP Racing F3 Flight Control
-Metallic Case Design
-Powerful Motor Design

Package Included:
Devo7 Right Hand Throttle Version:
1x Walkera F210 Racing Drone
1x 700TVL Camera
1x OSD
1x Transmitter
1x Receiver
1x DEVO 7 ( Right Hand Throttle)
1x Battery
1x Power Adapter

Devo7 Left Hand Throttle Version:
1x Walkera F210 Racing Drone
1x 700TVL Camera
1x OSD
1x Transmitter
1x Receiver
1x DEVO 7 ( Left Hand Throttle)
1x Battery
1x Power Adapter

BNF Version:
1x Walkera F210 Racing Drone
1x 700TVL Camera
1x OSD
1x Transmitter
1x Receiver
1x Battery
1x Power Adapter
