A010201 LXF-CNC-3000 CNC Copy Routing Center

Описание: CNC Copy Routing Center
LXF-CNC-3000

Function:
 This Machine is Used for milling different size holes and grooves of aluminum profile.

Main Features:
 It adopts ball bearing movement device, high precision guide liner, rack and pinion and servo motor, insure the stable movement with high precision position and operation. X-axis is driven by rack and pinion, Y and Z axis is driven by guide screw
 It adopts high speed spindle motor, stable rotation, low noise, strong milling ability
 Worktable can be turned from -90°、0°and +90°to realize one time clamping three surface milling
 It adopts PLC, Intelligent Integrated Numerical Control System, concision and vivid human and machine interface to have easy operation

Main Parameter:
 Air Pressure: 0.5MPa~0.8MPa
 Voltage: 3P 380V 50/60Hz
 Air Consumption: 30L/min
 Input Power: 4.5KW
 Spindle Rotary Speed: 18000r/min
 Max. X axis stroke: 3000mm
 Max. Y axis stroke: 350mm
 Max. Z axis stroke: 250mm
 Overall Dimension: 3860*1500*1970mm
 Weight: 1100kg

Main components brand:
 CNC system: Honghai
 Stepper motor: Tianya
 Spindle motor: Wangjiannan/ HQD
 Switching Power Supply: Mean Well
 Frequency converter: Best
 Cylinder: SANWO
 Solenoid valve: SANWO
 Electrical components: CHINT

Tools:
 Common Milling Cutter Diameter :6mm/8mm
 Quick change chuck
