Isometric projections Problem no 6 isometric sheet computer aided engineering drawing
Автор: Srinivas A
Загружено: 2021-08-04
Просмотров: 34373
Описание:
computer aided engineering drawing #BCEDK103/203
This video explains the isometric projections problem using isometric sheets of engineering drawing, Isometric projection engineering graphics. Engineering Visualization
Problem No. 6.The Frustum of a square pyramid of sides 40mm and height 60mm rest on the center of the top of a square block of side 60mm and height 20mm. The base edges of the pyramid are parallel to the top edges of the square block. Draw the isometric projection of the combination of the solids. (Top face of frustum pyramid side is 20mm)
VTU Syllabus:-
Easy tips to understand engineering graphics
How to study engineering graphics
Engineering Visualization
Tips to solve projections of planes problems
• How to pass Computer Aided Engineering Dra...
Tips to solve projections of solids problems
• How to pass Computer Aided Engineering Dra...
Projection of planes solved problems
https://youtube.com/playlist?list=PLd...
Projections of solids solved problems
https://youtube.com/playlist?list=PLd...
Isometric projection solved problems
https://youtube.com/playlist?list=PLd...
#EngineeringVisualization #21EVN15/25
#CAED #EGDL #18EGDL15/25
First year engineering graphics
#computer aided engineering drawing
#computer aided engineering graphics
#CAED #EGDL #18EGDL15/25
Engineering graphics tutorials.
#computer aided engineering drawing
#computer aided engineering graphics
