HIGH PERFORMANCE MPPT CHARGER
Автор: Fuji Electronika
Загружено: 2022-10-30
Просмотров: 1449
Описание:
FUJI Dspic two phase interleaved MPPT solar charger is done by shifted phase modulation in interleaved switching .The Dspic will vary PWM duty cycle of interleave switching for obtaining the maximum power point. At a particular duty cycle the maximum wattage(V*I) is obtained. The Dspic will track this point continuously and ensure the working of MPPT charger is always at this maximum power point. With this method we get 30-40% extra energy than the panel directly connected to the battery.
Battery- 12V to 120V (optional)
Ampere- 50 Amps. max
PV.Voc - 50 to 300 V. max (optional)
FUJI electronika
http://fujielectronicsindia.blogspot.com
