Alat Berat SEM Wheell Loader 636D, salah satu brand Caterpillar Terlaris

Описание: Alat Berat SEM Wheell Loader 636D ini adalah salah satu brand Caterpillar yang terlaris di dunia,dan sudah terbukti kecanggihan nya

Main Specifications



Rated Load

kg3000



Operating Weight with Standard Bucket

kg9900

Bucket Capacity

m³

1.5-2.5

Wheel Base

mm

2740

Overall Dimension

mm

7305*2354*3182

Operating Specifications





Breakout Force

KN

113

Dump Clearance

mm

2988

Articulated Angle





37±1

Transmission



Transmission Type Countershaft,power shift





Transmission Gears



F4/R2

Torque Converter Type





Single stage 3 elements

Maker & Type





SEM TR100

Forward I/Reverse I



7.9/9.7

Forward II/Reverse II



14/31

Forward III/Reverse III



25/NA

Forward IV/Reverse IV



39/NA

Axle



Main Drive Type

Spiral bevel gear, single stage

Final Drive Reduction Type





Planetary type, single stage

Rear - Oscillating +/-





±12

Engine





Model





Weichai WP6G125E22

Rated Power

kW

92

Rated Speed

r/min

2200

Displacement

L

6.754

Implement Hydraulic





Implement System Type





Gear pump

Boom Raise Time

s

4.65

Hydraulic Cycle Time

s

8.34

System Presure Setting

MPa

18

Brake System





Service Brake Dry & caliper, air to oil control





Parking Brake "Drum type shoe brake, spring applied & oil released"Steering System  Steering System System Type Shared FlowSteering Pump TypeMpaGear pumpSystem Presure Setting 14Steering Angle (L/R) 37±1Tires  Size 17.5-25Type PRLayer 12Txtured Type L-3
