Shutout Puzzle with SketchUp animation "solution".
Автор: Alex Kara
Загружено: 2024-10-26
Просмотров: 102
Описание:
Beside some idle chatter, the SketchUp animation that steps through the assembly solution one step (scene) at a time, is imbedded starting at
3:55 into the video.
The Sketchup model is designed for cutting this puzzle by a laser/CNC on 3mm and 6mm MDF/timber... can be exported a an STL file for 3D printing. The model uses "finger joints so if the thickness of the timber is changed (eg. 1/8" and 1/4"), the finger joints would need to be modified accordingly... be easier to dress down the timber.
The SketchUp model can be downloaded from the 3D Warehouse here,
https://3dwarehouse.sketchup.com/mode...
the 1.5 upsize from here,
https://3dwarehouse.sketchup.com/mode...
and the A4 PDF solution can be downloaded from,
https://u.pcloud.link/publink/show?co...
