Product Introduction:
Using to fixφ10mm,16mm, 20mm water pipe of underfloor heating system, the same standard with European technology and quality. It can speed up the installation effectively compared with traditional clips installation and the standard 50mm nob distance to install flexibly and heat emission evenly. The PS panel thickness ranging from 0.6-1.0mm and base EPS nob board also have different insulation thickness. Earthmother specialized R&D team also can help customers to develop molds for customized products.
Product Name:
Castellated PS Panel
Insulation Size:
1200x800mm
Total Size:
1250x850mm
Total Thickness:
30mm
Base Insulation Thickness:
10mm
PS Sheet Thickness:
0.6/0.8/1.0mm
Density:
35 Kg/m³
Compressive Strength:
≥250kPa
Thermal Conductivity:
0.034W/(m·K)
Temperature Stability:
≤70°
Product Feature:
Perfect undercut design to fix pipe tightly (卡管紧,倒扣)
Standard pipe distance and quick installation (间距标准)
360 suspended design to max heat emission (360 包裹)
Good thermal & sound insulation (隔热、隔声)
