How to connect a SEGGER Flasher in-system programmer to a target device

Описание: This video shows you how to figure out the required adapter, wiring, pinout, and configuration in order to connect your SEGGER Flasher in-system programmer to a target device.

If you’re enjoying this video and would like to see more, please like and subscribe!
We're just starting out, so your support is extremely important to us!

00:00 Introduction
00:27 Checking Flasher device support
02:11 Downloading and installing the Flasher SW Pack
03:10 Identifying the target board connector used for programming
03:45 10-pin Arm Cortex Debug connector
05:47 20-pin Arm Cortex Debug & Trace connector (0.05" pitch)
07:56 10-pin needle adapter footprint
08:56 6-pin needle adapter footprint
09:36 20-pin Arm debug connector (0.1" pitch)
10:00 Finding an adapter for other types of debug connectors
11:22 Information about the pinout of the Flasher 20-pin connector
12:25 Using the UART Port feature of the Flasher Hubs / Flasher ATE2
13:47 Getting the Flasher ready for programming using SEGGER U-Flash
14:22 U-Flash wiring diagrams
15:50 SEGGER J-Flash software
16:42 SEGGER J-Flash SPI software
17:50 Summary

Link to the SEGGER Flasher 20-pin connector pinout for JTAG:
https://kb.segger.com/Flasher_-_Hardw...

Link to the SEGGER Flasher 20-pin connector pinout for SWD:
https://kb.segger.com/Flasher_-_Hardw...

Link to the SEGGER Flasher 20-pin connector pinout for cJTAG, SPI, and QSPI, as well as target board design recommendations:
https://kb.segger.com/20-pin_J-Link_C...

Link to more information on the Flasher Hub / Flasher ATE2 "UART Port" feature:
https://kb.segger.com/Flasher_Hub_-_U...

Link to the list of supported SPI Flash memories:
https://www.segger.com/supported-devi...

Please feel free to leave comments below!

Happy programming!
