200920 Valve Studio - Viewer Question - 6L6 Push Pull Design
Автор: Craig Hollabaugh
Загружено: 2020-09-20
Просмотров: 588
Описание:
Today I'm answering this question, "Why do datasheets show OPT primary impedance go down as plate voltage goes up?". To answer, I look at the design value interplay of plate voltage, screen voltage, bias point, speaker impedance and OPT turns ratio and hopefully show that the question's answer is little more than a simple calculation.
beamPentodePushPullBiasing jupyter notebook
https://github.com/holla2040/valvestu...
160629 Valve Studio - Marshall JCM800 2205 Determining the Bias Point From EL34 Data Sheet
• 160629 Valve Studio - Marshall JCM800 2205...
Frank's GE-6L6GC
https://frank.pocnet.net/sheets/093/6...
The Valve Wizard - The Push-Pull Power Output Stage
http://www.valvewizard.co.uk/pp.html
Aiken Amplification - Idle Current Biasing - Why 70 percent?http://www.aikenamps.com/index.php/id...
Engauge Digitizer
https://markummitchell.github.io/enga...
