Duplo used booklet maker System 5000 - LA-POSTPRESS -
Автор: LA-POSTPRESS
Загружено: 2017-06-14
Просмотров: 416
Описание:
offer consists of:
2 collators DC-10/60
lifting unit LUL-HM
bookletmaker DBM-500
trimmer DBM-500T
preset kicker DBM-K
conveyor DBM-LS
year of manufacturing: 2007
numbers of clicks: 5.6 mio
Duplo System 5000
booklet maker
2xDC-10/60: collators
number of bins: 10; totally 20
paper size:
width: min. 120mm, max. 350mm
length: min. 148mm, max. 500mm
paper weight: 0-300g/sqm
loading volume: 60mm
feeding system: belt suction feed system
conveyance system: roller belt conveyance system
power supply: 120 to 240 V 50/60 Hz
power consumption: 9.5A (120 V 60 Hz), 4.5A(220-240V, 50Hz)
DBM-500: stitcher folder
paper size: min. 120x170mm; max. 350x500mm
process speed:
5000 pcs/h, A5
4600 pcs/h, A4
4000 pcs/h, A3
No. of stitches 0 to 2
stitch thickness within 5mm
wire diameter #25 to #27
folding capacity: below 25 sheets
dimensions: 2,230 (W) x 865 (D) x 1300 (H)
ratings: 120 to 240 V 50/60Hz 6.5-3.8A
weight: 412kg
DBM-500T: Trimmer
booklet size: min. 85x120mm; max. 250x356mm
trimmed booklet size: min. 75x120mm
speed: ut to 5000 sets per hour
power consumption: 120V 690Hz 10A
dimensions: 700mm x 635mm x 1094mm
weight: 532 lbs (241kg)
