HVAC dehumidification occurs when the dry bulb, wet bulb, and dewpoint intersect.

Описание: Did you know that fog formation is an excellent visual representation of saturated air?

I'm always looking for an opportunity to talk psychrometrics, and this morning, I found one.

I'm a total nerd, for sure.

We get fog when the dry bulb, wet bulb, and dewpoint intersect.

This is exactly what happens when air leaves a properly working cooling coil!

Once the air reaches its dew point temperature (at which it becomes saturated), water vapor condenses out.

We see this behind me and in a drain pan of an air handler.

Psychrometrics is a fundamental science of HVAC engineering and design, and as HVAC professionals, it is crucial to understand psychrometrics for several important reasons:

Efficient System Design, Comfort and Indoor Air Quality, /HVAC System Efficiency, HVAC Equipment Selection, Load Calculation, Troubleshooting and Maintenance, and Sustainable Design.

Want to learn more about Psychrometrics?

Visit our YouTube Channel    / @hvac-tv
