Building and testing a XUM1541-II adapter for connecting a Commodore 1541 floppy drive to a PC

Описание: Check out https://PCBWay.com for affordable PCB's and other services.
In this video I build a XUM 1541-II adapter that is based on the Zoomfloppy adapter.
This makes it possible to connect a 1541 floppy disk drive to the USB-port of a modern PC, and copy floppy disks over to that PC, or do other disk-operations using OpenCBM commands.

The adapter consists of an Arduino pro micro microcontroller, but is otherwise fairly simple.

Contents:
0:00 Introduction
1:53 Building the device
10:00 Programming the arduino
19:20 Testing the device
23:48 Conclusion
