Vending Machine using FSM | in QUARTUS II & PROTEUS
Автор: Kaushik Biswas
Загружено: 2020-12-18
Просмотров: 21891
Описание:
Hello Everyone!!!
This video is about our project 'Vending Machine using FSM' on the course "Digital Electronics Laboratory" in Bangladesh University of Engineering and Technology. This project is performed using both verilog code and circuit simulation. Verilog code is written in QUARTUS II & circuit is designed in PROTEUS. We hope that it will be helpful for anyone working on this topic in future. For any queries comment below or you can contact us with the Email provided.
#Vending_Machine #FSM #Verilog
#Contact
Email: [email protected]
Facebook: / dkaushikbiswas
Instagram: / dkaushikbiswas
Sections:
0:00 Intro
0:20 What is a Vending Machine?
1:10 What is FSM?
2:47 State Diagram
6:02 Verilog Code in QUARTUS
8:38 Output Waveforms of the Code
10:32 Circuit in PROTEUS
13:30 Circuit Simulation
