Snapmaker 2.0 CNC Brace Mod
Автор: E Tech Labs
Загружено: 2023-02-05
Просмотров: 6129
Описание:
This roller brace design is something I have been working on for the last year as the Snapmaker 2.0 (SM) has a good deal of slop in its linear modules. Some may say "you just need to open up and tighten the internal rollers in your linear modules" but believe me when I say that is not the issue... It is a pretty well known fact in the SM community forums that these machines have a number of shortcomings especially when it comes to the rigidity and constraints of motion in its linear modules while using the CNC functionality. Therefore I have created this mod which is very easy and cheap for anyone to implement! The goal of this specific mod is to remove the rotational slop of the X-Axis by bracing it at the connection points to both Z-Axis linear rails. This effectively reduces the "splaying out" of the tool when making CNC cuts which improves the tolerance of the end product and prolongs tool life.
Thingiverse Design Files: https://www.thingiverse.com/thing:582...
Snapmaker Forums Post: https://forum.snapmaker.com/t/cnc-bra...
