I Built a Portable Super Nintendo - Pt2
Автор: Restore Technique
Загружено: 2020-12-25
Просмотров: 406851
Описание:
I modified a Super Nintendo controller to build a custom SNES Portable. Raspberry Pi Zero build. Checkout Part 1 first!
Part 1: • I Built a Portable Super Nintendo - Pt1
.........................................................
Subscribe & check out my other tech restoration and mod videos!
Follow me on Instagram: / restoretechnique
Buy Me a Coffee 😄 : https://www.buymeacoffee.com/restoretech
Filmed on: Samsung S10e
Music:
Back To The Future Jellyfish - NoMBe
Calvin Harris - josh pan
Love Will Find A Way - Michael Ramir C. - https://mixkit.co
Software:
PinkyPi X for the GamePi15
PinkyPi prebuilt image, based off RetroPie 4.5.1
Using fbcp-ili9341 display driver (60hz!!)
Using RetroGame GPIO controller driver.
Using PiSNES as default SNES emulator
From https://www.crackedconsole.com/
Games featured:
Super Mario World
Super Punch-Out!!
Super Double Dragon
If the following Tools and Parts lists helped you, please considering leaving a comment :)
(not affiliate links)
Parts List:
Original SNES Controller
Raspberry Pi Zero
WaveShare GamePi15 hat - https://www.waveshare.com/gamepi15.htm
SanDisk Ultra 16GB MicroSD card - https://www.officeworks.com.au/shop/o...
Little Bird 3.7V 600mAh Lithium-Polymer Battery - https://www.littlebird.com.au/product...
Micro USB breakout boards - https://www.aliexpress.com/item/33049...
Mini HDMI breakout board - https://www.aliexpress.com/item/33049...
6x6mm Button Switches, 1 x 8mm tall, 2 x 7mm tall - https://www.ebay.com.au/itm/15PCS-tac...
Button caps 5x3.1 - https://www.aliexpress.com/item/33000...
SPDT Slide Switch - https://www.ebay.com.au/itm/10-Pack-B...
30 pin, 0.8mm pitch, Flat Flex Cable (trimmed to 20 pin) - https://www.aliexpress.com/item/88346...
28AWG Silicon wire - https://www.jaycar.com.au/light-duty-...
30AWG Kynar wire - https://www.jaycar.com.au/blue-wire-w...
32AWG Magnet wire
Selley's 2 part epoxy
Selley's Knead It epoxy putty
Tools:
Yihua 936 Soldering Iron
Yihua 2008D Hot Air Rework Station
Ozito 170W Rotary Tool
Drill Press (Aldi)
Phillips Head #0 Screwdriver
Custom fume extractor - • DIY Soldering Fume Extractor using a PC Fan
Tec 305-12 hot glue gun
Kapton tape
Goot Wick desoldering braid 3.0mm & 1.5mm - https://www.jaycar.com.au/1-5mm-goot-...
KingBo RMA-218 Flux
ChemTools 99.8% Isopropyl Alcohol
Mechanic UV Solder Mask - https://www.aliexpress.com/item/40008...
UNI-T UT71D Multi-meter
Trojan Files
Dick Smith Precision Pliers
240 Grit Sandpaper
Rotary tool cutting blades (Ozito, Dremel, eBay)
Woolworths Essentials dish detergent
