How to find TS Parameters of woofer 🔊 Thiele/Small Parameter measurement With REW💻

Описание: Hi, thanks for watching our video about Woofer Tester🔊 Thiele/Small Parameter measurement With REW💻!
The Thiele/Small (T/S) parameters are a set of measurements that are used to describe the electrical and mechanical characteristics of a speaker or driver. These parameters include the resonant frequency (Fs), the electrical resistance of the voice coil (Re), the total mass of the moving parts of the speaker (Mms), and the compliance of the suspension (Cms). Measuring the T/S parameters of a speaker can be useful for designing enclosures and crossover networks, as well as for characterizing the performance of a speaker.

One way to measure the T/S parameters of a speaker is to use a software tool called REW (Room EQ Wizard). REW is a free, open-source program that can be used to analyze the frequency response and impulse response of a speaker system and to calculate the T/S parameters based on those measurements. To measure the T/S parameters with REW, you will need a computer with a sound card and a microphone, as well as a speaker and a signal generator. You will also need to calibrate the microphone and set up the software to make the measurements. Detailed instructions for using REW to measure T/S parameters can be found in the documentation for the software or by searching online.
#TS#Parameters#Woofer

REW Download Link: https://www.roomeqwizard.com/


TIMESTAMPS
0:00 Intro
0:53 DIY Woofer Tester Circuit
03:55 Before calibrating DIY Woofer Tester
05:11 REW hardware configuration
06:17 REW open circuit calibration of DIY Woofer Tester
07:04 REW Short circuit calibration of DIY Woofer Tester
07:25 REW reference calibration of DIY Woofer Tester
08:00 Before measuring impedance curve with DIY Woofer Tester
08:40 Impedance Measurement with DIY Woofe Tester and REW
09:30 Added mass method and choosing cone weight
11:22 Measurement of TS Parameters with REW
13.30 Troubleshooting DIY Woofer Tester.
