Appli Parts APPR-065 Potential Relay 065, Coil Voltage 332 V, Min Pick up 168 V, Max Pick up 182 V

Описание: Appli Parts APPR-065 Potential Relay 065, Coil Voltage 332 V, Min Pick up 168 V, Max Pick up 182 V, Max Drop Out 90 V, 50/60 Hz Universal replacement for HVAC and Refrigeration units.

Use: Potential Relays are used to engage and disengage the Start Capacitor once the unit is started. Failing to disconnect the Start capacitor will cause electrical damage.

Specs: Coil Voltage is 332V. Minimum Pick Up 168V. Maximum Pick Up 182V.

Maximum Drop Out 90V. Can be used in 50/60 Hz applications.

Connections: There are 6 sets of 1/4in connectors. 1-2 Normally Closed Contacts. 2-5 Coil Terminals. 4-6 Dummy Terminals.

Universal: Replaces many part numbers and brands with the same electrical specs.

Replaces: 9065, 19004, 19165 90-3, 90-7, 90-40, 90-65, 040-0001-02, 040-0001-11, 82778

Weight : 0.4 LBR
Volume : 0.009 FTQ
Model : APPR-065
UPC-EAN : 814245027704

Universal replacement Potential Relay

This part is a replacement for original part numbers and brands equal but not limited to:

8201-125

75FC5, 11873, 11873-1, 19037-12

A4033-1, A40231-1, A40333-1, B41511-1, B51109-1

1084296

275-13, 275-B-16, 304-9820-01, 304-13599-03, 325-S-6303

1456-521, 1456-571, 1456-585, 1456-603, 1456-773, 1456-780, 1456-794, 1456-825, 1456-887, 1456-902, 1456-917

110441

58340-D8

38GK57901D1, HN61HB498, HN61HB504, HN61HZ025, HN61HZ043, HN61HZ045, HN61HZ050, HN61HZ051, HN61HZ059, HN61KA04D, HN61KA054, HN61KA-040, HN61KB023, HN61KB036, HN61KB-049, HN61KB-050, HN61KB-070, HN61ZB-010, HN61ZB-030, HN61ZB-190

1424130, 1746896

2003501, 2003664, 2005519, 2015519, 2025533, 2540175, 3408587

5600326

6102-214, 6152-171, 6247-307, 6248-307, 6258-307, 6922-315, 6930-315, 6930-316

040-0001-02, 040-0001-11, 040-0001-37, 040-0003-04, 040-0003-08, 040-0003-23, 040-0003-27, 040-0006-02, 040-0006-03, 040-0007-06, 040-0008-06, 040-0011-01, 040-0011-03, 040-0012-00, 040-0014-01, 040-0014-03, 040-0014-08, 040-0046-03, 040-0046-08, KK640, KK641, KK649, KK649-1, KRV540, MRV540-1, UD5540, UG7580, UG7582, UH9541-1, UJ8541, YF75-40, YF7543

DNP-02-0374

E10832, E10836, E11081

16-4-010B-1, 16-4-012B-8, 16-4-013B-1, 16-4-013B-2, 16-4-015B-7, 16-4-029B-1, 16-4-029B-9, 16-4-029B-11

600-659-00, 600-752-02, 600-752-25, 700-093-01, 1281227, 1281232, 1281249, 1281420

6540336, 6543110, 6543988

PR065

3ARR3-3AP, 3ARR3-3P, 3ARR3-3R, 3ARR3-5P, 3ARR3-5R, 3ARR3-5S, 3ARR3-5T, 3ARR3-22S, 3ARR3-A3P2, 3ARR3-A3P3, 3ARR3-A3R2, 3ARR3-A3R3, 3ARR3-A5P2, 3ARR3-A5P3, 3ARR3-A5R3, 3ARR3-AJ3R3, 3ARR3-B3AP3, 3ARR3-B3P6, 3ARR3-B3R3, 3ARR3-B3R4, 3ARR3-B3R5, 3ARR3-B5P4, 3ARR3-B5R4, 3ARR3-C5R3, 3ARR3-CD3V2, 3ARR3-CT3AP4, 3ARR3-CT3P3, 3ARR3-CT3P6, 3ARR3-CT3R5, 3ARR3-CT64B5, 3ARR3-CV3P4, 3ARR3-CV25S4, 3ARR3-D3R3, 3ARR3-EE3P1, 3ARR3-EG5AR6, 3ARR3-EG5R6, 3ARR3-FJ3BR3, 3ARR3-FJ3P3, 3ARR3-G3P3, 3ARR3-H3P2, 3ARR3-H3R3, 3ARR3-J3AP6, 3ARR3-J3P2, 3ARR3-J3P6, 3ARR3-J3R2, 3ARR3-J3R3, 3ARR3-J3R6, 3ARR3-J5P3, 3ARR3-J5S3, 3ARR3-J5T4, 3ARR3-K3P2, 3ARR3-K3P3, 3ARR3-K3P4, 3ARR3-K3P5, 3ARR3-K3R3, 3ARR3-K3R4, 3ARR3-K5R4, 3ARR3-K5T3, 3ARR3-L3P6, 3ARR3-N3AP3, 3ARR3-N3P3, 3ARR3-N3P6, 3ARR3-N3R3, 3ARR3-R3R4, 3ARR3-T3AP3, 3ARR3-T3P2, 3ARR3-T3P3, 3ARR3-T3R2, 3ARR3-T3R3, 3ARR3-T3R4, 3ARR3-U3P2, 3ARR3-U3P5, 3ARR3-U3R3, 3ARR3-U3S5, 3ARR3-W3R6, 3ARR3-Y3R3, 3ARR3-Z3P1, 3ARR3-Z3P4, 3ARR3-Z3R3, 3ARR3-Z3R4, 3ARR3-Z5R4, 115174, 117533, 119281, W71305, W81189, W92405

5-0003A

93589

420507R91, 421068R91, 421119R91

E-5654-1

65

46-00-588

B119009-2, B119009-4, B119009-8, B119009-9, B119009-12

C-11873-1, C-11873-2

110441, 157546, 580410

413920, 622116, 622166, 622984

20-5547, 20-6591, 20-7482

22-9636

5192-33, 5192-43, 5192-63, 5192-85, 5192-114, 5192-134, 5192-135, 5192-136, 5192-265-7, 5192-265-8, 5192-273-1, 5192-273-2

9701-1, E10832

H80-2103, H80-2107

90-3, 90-7, 90-40, 90-65, 128--2--2-P, 128--2--3-R, 128--2--4-P, 128--2--4-R, 128--2--4-S, 128--6--2-P, 128--6--3-P, 128--6--3-R, 128--6--4-P, 128--6--4-R, 128--6--4-S, 91255-206, 91255-208, 91255-209, 91255-218, 91255-219, 91255-220, 91255-411, 91255-911, 91255-935, 91255-1200, 91255-1201, 91255-1202, 91255-1203, 91255-1204, 91255-1205, 91255-1560, 91255-1561, 91255-1562, 91255-1563, 91255-1564, 91255-1565, 91255-1566, 91255-1567, 91255-1568, 91255-1569, 91255-1580, 91255-1581, 91255-1582, 91255-1583, 91255-1584, 91255-1585, 91255-1586, 91255-1587, 91255-1588, 91255-1589, 91255-1620, 91255-1621, 91255-1622, 91255-1623, 91255-1624, 91255-1625, 91255-1626, 91255-1627, 91255-1628, 91255-1629, 91255-1680, 91255-1681, 91255-1682, 91255-1683, 91255-1684, 91255-1685, 91255-1686, 91255-1687, 91255-1688, 91255-1689, 91255-8182, 91255-9111, 91255-9116, 91255-9117, 128990-1246B, 128990-1623K, 128990-1734B

PRB-2

5192-78, 5192-85, 5192-136

42-18282-07, 42-18282-09, 42-18528-02, 42-18528-06, RES-552

1456-585, 1456-603

0410-134

U18-810

17902, 22816, OAS17474, OAS17902, OAS27666, OAS27672
