Troubleshooting Tips: Op Amps - Power Supply Rejection Ratio
Автор: Texas Instruments
Загружено: 2019-08-26
Просмотров: 2106
Описание:
Watch TI Precision Labs the electronics industry’s first comprehensive online classroom for analog engineers.
https://training.ti.com/ti-precision-...
Understanding how to verify datasheet specifications such as power
supply rejection ratio (change in offset versus change in power supply
voltage) is critical to the application troubleshooting and debugging
process. In this training the false summing junction circuit is utilized to
demonstrate how to determine the PSRR of a linear amplifier. At the system
level an offset anomaly versus power supply voltage may result in the
following signatures:
Increased or decreased output voltage compared to the nominal
Anomalous reading observed by ADC
Unexpected sensor reading
Download the Analog Engineer's Pocket Reference e-book.
https://www.ti.com/amplifier-circuit/...
Watch TI board level troubleshooting video on the A-B-A swap
https://training.ti.com/ti-precision-...
Download and install TINA-TI, the preferred simulator used exclusively with TI Precision Labs - Op Amps.
https://www.ti.com/tool/TINA-TI
