Collins ART-13 - PA Plate Current Metering Circuit Repaired and New Mic Jack Socket Installed
Автор: Gerry O'Hara
Загружено: 2023-09-17
Просмотров: 425
Описание: Although I had succeeded in coaxing the ART-13 to deliver around 100W output on 20M, the PA Plate setting on the front panel meter was not working. This fault was traced to a broken pin in the chassis mounted socket that connects to the dynamotor. The broken pin was replaced with thick copper wire epoxied into place. The PA Plate current setting on the mtere is now functional. I also replaced the non-standard microphone socket with a 1/4" jack socket.
