Relay Computer - New Register and Backplane

Описание: Although my first register worked as designed, I soon got the feeling that it wasn't going to work out - coding and cabling would have been horrendous! Fortunately, this led me to do some more research and finding a much better solution for both the registers and how it will all tie together.

If you would like to support my channel and get access to some extra stuff, then please head over to Patreon:
  / dipdot

Thank you for watching, and as always I welcome any feedback or ideas for future projects!

CHAPTERS
0:00 Intro and Acknowledgments
0:42 Architecture (Focus on Registers)
1:40 Register Woes
2:04 Flaw 1 - Reset Line = Coding Nightmare
3:39 Flaw 1 Solution: Dr. Porter to the rescue
6:04 Flaw 2 - Avoiding the Rats Nest
6:55 Flaw 2 Solution: Backplane to the rescue
8:11 Card Edge Design - Interpreting the Data Sheet
9:42 Card Edge Design - Footprints in the PCB
11:14 Interlude - My cameras don't record soldering well...
11:38 The new Backplane and Registers!
13:52 First Test - Manual "button-mashing" method
14:46 Automated Test Rig Setup Walkthrough
15:48 Second Test - Automated - Loading values from data bus
16:00 Third Test - Automated - Passing values between registers via the data bus
16:20 High-speed Test - Automated - 0 to 60 in 10.4 days
16:41 Outro
