11- Delta PLC and VFD Communication using PLC Link RS-485

Описание: In this video, we explore one of the most powerful features in Delta Automation: the "PLC Link". Learn how to establish communication between a Delta PLC and a Delta VFD (Inverter) via RS-485 with zero complex Modbus coding. We'll walk through the VFD parameter settings and the ISPSoft configuration using the PLC Link Wizard for a fast and reliable connection.
___________________________________
00:00 Video Introduction and Project Overview
02:12 RS-485 Hardware Wiring between PLC and VFD
02:56 Delta VFD Parameter Configuration for Communication
05:19 ISPSoft PLC Link Wizard Step-by-Step Setup
08:28 Understanding MS300 VFD Internal Registers
10:51 VFD Start and Stop Control via RS-485
14:34 How to Activate and Enable PLC Link
17:14 Practical Test: Motor Speed Control via RS-485
19:40 Reading MS300 VFD Parameters
21:23 Converting Parameter Numbers from Decimal to Hexadecimal
23:00 Controlling VFD Parameters using PLC Link
